Meet NSF/ANSI Standards 177 for chlorine reduction
Lasts 6 months or 5,000 gallons (whichever comes first),depending on water quality
Includes KDF-55 shower filters, giving you more filtration power for your money
Certified to process water at 2.0 gallons per minute, which is the same flow regulation as most standard shower heads
Utilizes KDF-55 media to remove 95% or more of chlorine and aids in the reduction of hard water contaminants
Utilizes crystalline quartz for softer & lighter shower feel
Installs in minutes – no special tools or professional help required
Fits most standard plumbing fittings and shower heads
No back-flushing needed
INSTALLATION
1. Remove the showerhead from the shower arm
2. Screw the ECO-502 Shower filter onto the shower arm
3. Screw the showerhead onto the ECO-502 shower filter
4. If leaks appear tighten,reinstall or use Teflon tape
5. Do not use with Shut-off valve
OPERATION
BEFORE ENTERING THE SHOWER
1. Activate the filter by turning the shower-water to “full-hot’’
2. Cool to desired temperature before entering the shower. To enure over 95% free-chlorine removal. replace the model Filter Cartridge every. 6 month or 5000 gallons. Whichever comes first
MAINTENANCE
2. Remove and reverse the ECO-502 Cartridge ,Check that the O-Rings located inside each of housing, Halves are properly seated to the O-Rings will hold them in place.)
3. Close by screwing filter housing Halves clockwise.
4. This procedure may be repeated as necessary
ECO-502CARTIDGE REPLACEMENT:
Replace every 6 months according to individual water conditions by performing the following procedure:
1. Open by unscrewing filter housing Halves, counter clockwise
2 Remove and replace the used filter with the new. Check that the O-Ring located inside each of the Shower Filter housing Halves is properly seated in the O-Ring Channel.(Note: A small amount of Vaseline applied in the O-Ring Channel will hold the O-ring in place)
3. Close by screwing filter housing Halves clockwise.
REMINDER
Is designed to remind you to change the filter cartridge 6 months
1. Use a pen to till out the installation and replacement date
2. Peel sticker off of backing and apply to a corner of a dry mirror (or any glass surface)
Performance Data:
Shower Filter Model ECO-502
Rated Service Flow-9.5 Liters per minute/2.5 gallons per minute
Rated service Life at 95% free chlorine removal-18975 liters/5000 Gallons
Maximum working pressure-860 kilo pascals/125 pounds per square inch
Maximum operating temperature-49°Celsius/ 120 Fahenheit
Installation- Attaches to shower-arm. No Tools Required
Notes:
While testing was performed under standard laboratory condition, actual performance may vary
This system is not intended to used as a drinking water treatment unit
Both the system and installation must comply with applicable state and local regulations.
